My favorite cutaway artist is Shin Yoshikawa. Here is his webpage. I have a few of his drawings on my walls. I gave a friend of mine who is restoring a Rolls-Royce Silver Ghost a print of Shin's Silver Ghost and he loved it.

http://www.kaiartintl.com/home
Great stuff. Here are a couple of his I grabbed off of his website that were of interest to me since I had both when I was young.
-DonC9D519E2-BB2B-4323-9E57-6AA1FCD5B484.jpeg8BBF1311-27A6-4A7D-B8ED-AE85E11668E4.jpeg


Tostal

Well-known member
Joined
Feb 1, 2020
Messages
893
Location
The Emerald Isle
Book of British motorcycle road tests from 1971. I've shown the pages on the Vincent- H.R.D "Black Shadow" 998c.c. high camshafts, o.h.v. tested on Jan 26, 1950. I hope those interested in 'the Vincent' are able, despite the fuzziness, to read this road test from a bygone era.
IMG_20221210_215403 (2).jpg
Scan_20221211 (23).pngScan_20221211 (24).png
Scan_20221214 (8).png

T~

Last edited:

Tostal

Well-known member
Joined
Feb 1, 2020
Messages
893
Location
The Emerald Isle
Cutaway of the "Big Bonnie" engine, a 750c.c. version of the original 650 c.c. Triumph Bonneville engine, from c. 1974 when Triumph motorcycle were just about clinging on. Notice that while the specs say that max power was developed at 7,000 r.p.m., they don't say how much (or little) was made - (it was significantly less than contemporary Japanese 750c.c. offerings).

T~


Farmer J.

Well-known member
Joined
Sep 18, 2016
Messages
1,995
Location
UK, Cornwall/Hertfordshire.

2oolhound

Well-known member
Joined
Dec 18, 2010
Messages
5,918
Location
BC Canada
I knew a Black Shadow was fast, but i didn't know it was THAT fast!

I was expecting it to have been faster, after all the speedometer went all the way to 150 mph.:giggle:

T~
122 mph was pretty respectful off the factory floor in 1950. It's what owners did with them when they got them home that made them really fast.

Case in point is legendary Burt Munro who in the 1960's created a land speed record of 178.95 mph on his 1920 Indian Scout (he was 68 years old). For those who haven't seen the movie about him "The World's Fastest Indian" it's one of the best movies you'll ever see, well worth the watch.

Sad to see this bygone era go when an individual could buy a bike, totally disassemble it into each tiny piece and refit it together again like a child's mechno set and race it. Todays super bikes are so sophisticated you'd need thousands hundereds of thousands of dollars to do this 50, 60 or 70 years after their production date if even possible.

Here's an exploded diag. of a 1975 850 Norton mc motor. You needed deep pockets
or mechanical abilities to keep one of these machines running. With diags. like these you quickly learned to keep the wheels going round.

850NortonEng Exploded.jpg
